Description
Product Description
| Category | Specification |
|---|---|
| HARDWARE FEATURES | |
| Standards and Protocols | IEEE 802.3i / 802.3u / 802.3ab / 802.3x / 802.1p |
| Interface | 8 x 10/100/1000Mbps Ports, Auto-Negotiation, Auto-MDI/MDIX |
| Fan Quantity | Fanless |
| Power Consumption | Maximum: 3.31W (220V/50Hz) |
| External Power Supply | External Power Adapter (Output: 9VDC / 0.6A) |
| Buffer Size | 1.5 Mb |
| LED Indicator | System Power; Link/Act indicators per port built into each RJ-45 port |
| Dimensions (W x D x H) | 6.2 x 4.0 x 1.0 in. (158 x 101 x 25 mm) |
| Max Power Consumption | 3.31W (220V/50Hz) |
| Max Heat Dissipation | 11.29 BTU/h |
| PERFORMANCE | |
| Packet Forwarding Rate | 11.9 Mpps |
| MAC Address Table | 4K |
| Packet Buffer Memory | 1.5 Mb |
| Jumbo Frame | 16 KB |
| SOFTWARE FEATURES | |
| Advanced Features | Green Technology, saving power up to 82%, 802.3X Flow Control, 802.1p/DSCP QoS, IGMP Snooping |
| Transfer Method | Store and Forward |
| OTHERS | |
| Certification | CE, FCC, RoHS |
| Package Contents | 8-Port 10/100/1000Mbps Desktop Switch, Power Adapter, Installation Guide |
| Environment | Operating Temperature: 0°C |
| Storage Temperature: -40°C |
|
| Operating Humidity: 10%~90%, non-condensing | |
| Storage Humidity: 5%~90%, non-condensing |
