| Hardware Features |
Interface |
48 × 10/100/1000 Mbps RJ45 Ports (8 × PoE++, 40 × PoE+), 4 × 10G SFP+ Slots, 1 × RJ45 Console Port, 1 × Micro-USB Console Port |
|
Fan Quantity |
3 |
|
Physical Security Lock |
Yes |
|
Power Supply |
100-240 V AC~50/60 Hz |
|
PoE Ports (RJ45) |
802.3at/af/bt compliant; Ports 1-8 (up to 90 W), Ports 9-48 (up to 30 W) |
|
Power Budget |
750 W |
|
Dimensions |
17.3 × 13.0 × 1.7 in (440 × 330 × 44 mm) |
|
Mounting |
Rack Mountable |
|
Max Power Consumption |
913.4 W (110V/60Hz) (with 750 W PD connected) |
|
Max Heat Dissipation |
3114.69 BTU/hr (110 V/60 Hz) |
| Performance |
Switching Capacity |
176 Gbps |
|
Packet Forwarding Rate |
130.9 Mpps |
|
MAC Address Table |
16 K |
|
Packet Buffer Memory |
12 Mbit |
|
Jumbo Frame |
9 KB |
| Software Features |
Quality of Service |
8 priority queues, 802.1p CoS/DSCP priority, Bandwidth Control, QoS actions |
|
L2 and L2+ Features |
128 IP Interfaces, Static Routing, DHCP Server, Relay features |
|
L2 Multicast |
Supports 1000 IGMP groups, IGMP Snooping, MLD Snooping |
|
Advanced Features |
Automatic Device Discovery, Batch Configuration, Intelligent Network Monitoring |
| ISP Features |
Protocols |
L2PT, DLDP, PPPoE ID Insertion, ERPS, 802.3ah Ethernet Link OAM |
| VLAN |
VLAN Group |
Max 4K VLAN Groups, 802.1Q Tagged VLAN, Private VLAN |
| Access Control List |
ACL Types |
Time-based, MAC, IP ACLs, Combined ACLs, Policy actions |
| Security |
Security Features |
IP-MAC-Port Binding, DHCP Snooping, DoS Defend, 802.1X |
|
Port Isolation |
Yes |
| IPv6 |
IPv6 Features |
Dual IPv4/IPv6, MLD Snooping, IPv6 applications |
| MIBs |
Supported MIBs |
Various standard and private MIBs |
| Management |
Omada App |
Yes (requires Omada Hardware/Cloud-Based Controller) |
|
Centralized Management |
Multiple controller options |
|
Cloud Access |
Yes (requires specific controllers) |
|
Zero-Touch Provisioning |
Yes (requires Omada Cloud-Based Controller) |
| Others |
Certification |
CE, FCC, RoHS |
|
Package Contents |
SG3452XMPP Switch, Power Cord, Rackmount Kit |
|
System Requirements |
Various Windows, MAC OS, NetWare, UNIX/Linux |
|
Environment |
Operating Temp: 0–40 ℃ (32–104 ℉), Humidity: 10–90% RH |
