Description
Product Description
|
Specifications
|
||
|---|---|---|
| HARDWARE FEATURES | ||
| Processor | Qualcomm 1 GHz Quad-core CPU | |
| Interface | 2 LAN/WAN Gigabit Ethernet Ports | |
| Button | 1 Reset button on the underside | |
| Dimensions | Φ4.33 in. × 4.49 in. (Φ110 mm × 114 mm) | |
| Antenna | 4 internal antennas per Deco unit | |
| WIRELESS FEATURES | ||
| Wireless Standards | IEEE 802.11 ax/ac/n/a 5 GHz, IEEE 802.11 ax/n/g/b 2.4 GHz | |
| Frequency | 5 GHz, 2.4 GHz | |
| Signal Rate | 1201 Mbps (5 GHz), 574 Mbps (2.4 GHz) | |
| Transmit Power | FCC: <30 dBm; CE: <20 dBm (2.4 GHz), <23 dBm (5 GHz) | |
| Wireless Security | WPA-PSK, WPA2-PSK, WPA3 | |
| Advanced Functions | – Router/Access Point Mode | |
| – Optional Ethernet Backhaul | ||
| – TP-Link Mesh Technology: MU-MIMO, OFDMA, 1024-QAM, BSS Color, Auto Path Selection, Self-Healing, AP Steering, Band Steering, Beamforming | ||
| SOFTWARE FEATURES | ||
| Quality of Service | WMM | |
| IPv6 Support | Yes | |
| WAN Type | Dynamic IP/Static IP/PPPoE | |
| Management | Local Management, Remote Management | |
| DHCP | Server, Client | |
| Port Forwarding | Support | |
| Access Control | Blacklist | |
| Firewall Security | SPI Firewall | |
| Protocols | Supports IPv4 and IPv6 | |
| Advanced Features | Homecare: Antivirus, Parental Controls, Quality of Service | |
| – Speedtest | ||
| – Monthly Usage Reports | ||
| – Auto FW Update | ||
| – Expand Coverage by Adding more Decos | ||
| Guest Network | 2.4 GHz guest network * 1, 5 GHz guest network * 1 | |
| Beamforming | Support | |
| APP | Easy setup via Deco App | |
| OTHERS | ||
| Certification | CE, FCC, IC, NCC, BSMI, IDA, RCM, JPA, JRF, VCCI, KC, RoHS | |
| Package Contents | – Deco X20 (1-pack): 1 unit, 1 RJ45 Ethernet Cable, 1 Power Adapter, 1 Quick Installation Guide | |
| Smartphone/Tablet Requirements | iOS 9.0 or later, Android 4.4 or later | |
| Environment | Operating Temperature: 0℃~40℃ (32℉~104℉); Storage Temperature: -40℃~70℃ (-40℉~158℉); Operating Humidity: 10%~90% non-condensing; Storage Humidity: 5%~90% non-condensing | |
