| Device Type |
IP-camera |
| Connection type |
wired |
| Installation location |
inside, outside |
| Matrix resolution |
4 Mpx |
| Wi-Fi support |
no |
| Video standard |
IP |
| Type of instalation |
wall, ceiling, overhead |
| Form factor |
dome |
| Intended for use |
home, house, office, store, warehouse, production |
| Matrix type |
1/3” Progressive CMOS |
| Recording speed |
Main Stream: 4 МР (2560х1440) – 25 fps; 3 MР (2304х1296) – 30 fps; 1080P (1920х1080) – 30 fps; 720P (1280х720) – 30 fps; Sub Stream: 4CIF (704х576) – 30 fps; 640х360 – 30 fps; 2CIF (704х288) – 30 fps; CIF (352х288) – 30 fps |
| Camera motion sensor |
program |
| Lens type |
fixed |
| Focal length |
2.8 mm |
| Viewing angle |
97° |
| Optical zoom |
1x |
| Digital zoom |
1x |
| Light sensitivity |
0.01 Lx |
| Light distance |
30 m |
| Type of illumination |
infrared |
| Day-night mode |
yes, ICR filter |
| Memory card slot |
yes |
| Built-in microphone |
yes |
| Built-in speaker |
no |
| Video output |
1xRJ45 |
| Audio inputs |
no |
| Audio outputs |
no |
| Network output |
1xRJ45 |
| Network Interface |
1 RJ45 10M/100M Base-TX Ethernet, IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, RTP, RTSP, RTCP, RTMP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, QoS, SSL,SNMP |
| Type of memory cards |
microSD up to 128GB |
| PoE support |
yes |
| PoE type |
IEEE802.3 af |
| Video compression |
H.264, H.265, H.265+, MJPEG |
| Alarm Inputs-Outputs |
no |
| Alarm inputs |
no |
| Alarm outputs |
no |
| Modes |
2D/3D DNR / WDR / OSD / ROI |
| Streaming |
2 streams |
| PTZ control |
no |
| Built-in lightning protection |
no |
| Additional functions of camera |
motion detection, region of interest (ROI) |
| Moisture and dust protection |
IP67 |
| Vandal protection |
no |
| Browsers |
Chrome, Firefox, Safari, Edge, Opera |
| OS support |
Windows, MAC OS, IOS, Android |
| Powered by batteries / rechargeable batteries |
no |
| Integration with Ajax system |
yes |
| Mobile app |
EZView |
| Compatibility |
ONVIF (Profile S, Profile G, Profile T), API |
| Consumption |
4 W |
| Operating voltage |
12V DC |
| Dimensions (WхHхD) |
Ø 109 x 81 mm |
| Body color |
white |
| Body material |
metal, plastic |
| Weight |
0,36 кg |
| Temperature range |
-30…+60°C |
| Producing country |
China |
| Device class |
middle |
