Description
Product Description
| Mechanical | |
|---|---|
| Dimensions | Without Mount: 257 x 84 x 41 mm (10.12 x 3.31 x 1.61″) With Mount: 257 x 84 x 30 mm (10.12 x 3.31 x 1.18″) |
| Weight | 233 g (8.22 oz) |
| Mounting | Pole and Wall Mounting Kits Included |
| Hardware | |
| Networking Interface | (2) 10/100/1000 Ethernet Ports |
| Gain | 16 dBi |
| LEDs | Power, ETH1, ETH2, (4) Signal Strength |
| Max. Power Consumption | 9W |
| Power Supply | 24V, 0.5A Gigabit PoE Supply (Included) |
| Power Method | PoE or Passive PoE (Pairs 4, 5+; 7, 8 Return) |
| Supported Voltage Range | 24V ±10% |
| ESD/EMP Protection | ±24 kV Contact/Air |
| Operating Temperature | -40 to 70° C (-40 to 158° F) |
| Operating Humidity | 5 to 95% Noncondensing |
| Certifications | CE, FCC, IC |
| Operating Frequency (MHz) | |
| Worldwide | 5150-5875 |
| USA U-NII-1 U-NII-2A U-NII-2C U-NII-3 |
5150-5250 5250-5350 5240-5725 5725-5850 |
| Management Radio (MHz) | |
| Worldwide | 2412 – 2472 |
| US/CA | 2412 – 2462 |
