Description
Product Description
|
Specifications
|
||
|---|---|---|
| Dimensions | 442 x 285 x 44 mm (17.4 x 11.2 x 1.7″) | |
| Weight | Without mounting brackets: 4.5 kg (10 lb) With mounting brackets: 4.6 kg (10.2 lb) |
|
| Enclosure material | SGCC steel | |
| Hardware | ||
| Management interface | Ethernet In-Band | |
| Networking interface | (48) GbE RJ45 ports (4) 1G SFP ports |
|
| PoE interface | (32) PoE/PoE+ (Pins 1, 2+; 3, 6-) | |
| Total non-blocking throughput | 52 Gbps | |
| Switching capacity | 104 Gbps | |
| Forwarding rate | 77.38 Mpps | |
| Power method | Universal input, 100—240V AC, 50/60 Hz | |
| Power supply | AC/DC, internal, 240W | |
| Supported voltage range | 100—240V AC | |
| Max. power consumption | 45W (Excluding PoE output) | |
| Total PoE available | 195W | |
| Max. PoE wattage per port by PSE | PoE+: 32W | |
| Voltage range PoE mode | PoE: 44—57V PoE+: 50—57V |
|
| ESD/EMP protection | Air: ± 16kV, contact: ± 12kV | |
| Shock and vibration | ETSI300-019-1.4 Standard | |
| Ambient operating temperature | -5 to 40° C (23 to 104° F) | |
| Ambient operating humidity | 10 to 90% noncondensing | |
| Certifications | CE, FCC, IC | |
| Switching Features | ||
| Layer 2 features | IGMP snooping STP / RSTP with priorities and port-level disable Port isolation Storm control Voice VLAN Port mirroring LACP port aggregation Multicast / broadcast rate limiting MAC address blocking Flow control 802.1X control Jumbo frames Proprietary loop protection DHCP snooping / guarding Egress rate limit LLDP-MED Port restricted by MAC Device isolation with ACLs |
|
| Layer 3 features | – | |
| LEDs | ||
| System | Status | |
| Ethernet | PoE Speed/link/activity |
|
| SFP | Link/activity | |
