Description
Product Description
|
Specifications
|
||
|---|---|---|
| Dimensions | 229 x 136.5 x 31.1 mm (9 x 5.4 x 1.2″) | |
| Weight | 730 g (1.6 lb) | |
| Enclosure material | Metal housing with black powder coat | |
| Hardware | ||
| Processor | 4-core 1 GHz MIPS64 | |
| System memory | 1GB DDR3 RAM | |
| On-board flash storage | 4GB eMMC, 8MB SPI NOR | |
| Networking interface | (5) 10/100/1000 RJ45 ports (1) 1 Gbps SFP port (1) USB port |
|
| Management interface | (1) RJ45 serial port | |
| PoE interfaces | (5) 24V Passive PoE ports (2-pair and 4-pair) | |
| Power method | External AC/DC power adapter, 60W, 24V, 2.5A (Included) | |
| Power supply | External AC/DC adapter | |
| Supported voltage range | 16–30V DC | |
| Max. power consumption | 16W (Excluding PoE output) | |
| Passive PoE Max. wattage per port | 24W (24V, 1A, 4-pair) 12W (24V, 0.5A, 2-pair) |
|
| Button | Factory reset | |
| LEDs | Data ports: link/speed/activity, PoE SFP data port: link/activity |
|
| Button | Factory reset | |
| Mounting | Wall, rack* *With optional Rack Mount Kit, model ER-RMKIT. |
|
| Ambient operating temperature | -10 to 50° C (14 to 122° F) | |
| Ambient operating humidity | 10 to 90% noncondensing | |
| Certifications | CE, FCC, IC | |
