| HARDWARE FEATURES |
|
| Interface |
24× 10/100/1000 Mbps RJ45 PoE+ Ports, 4× Gigabit SFP Slots, 1× RJ45 Console Port, 1× Micro-USB Console Port |
| Fan Quantity |
2 |
| Physical Security Lock |
Yes |
| Power Supply |
100-240 V AC~50/60 Hz |
| PoE Ports (RJ45) |
802.3at/af compliant, 24 Ports (up to 30 W PoE Output per Port), Power Budget: 384 W* |
| Dimensions |
17.3×13.0×1.7 in (440×330×44 mm) |
| Mounting |
Rack Mountable |
| Max Power Consumption |
480.1 W (110 V/60 Hz) (with 384 W PD connected) |
| Max Heat Dissipation |
1637.14 BTU/hr (110 V/60 Hz) (with 384 W PD connected) |
| PERFORMANCE |
|
| Switching Capacity |
56 Gbps |
| Packet Forwarding Rate |
41.66 Mpps |
| MAC Address Table |
16K |
| Packet Buffer Memory |
12 Mbit |
| Jumbo Frame |
9 KB |
| SOFTWARE FEATURES |
|
| Quality of Service |
8 priority queues, 802.1p CoS/DSCP priority, Queue scheduling: SP, WRR, SP+WRR, Bandwidth Control |
| L2 and L2+ Features |
128 IP Interfaces, Static Routing, Static ARP, Proxy ARP, DHCP Server, Link Aggregation, Spanning Tree Protocol |
| L2 Multicast |
Supports 511 IGMP groups, IGMP Snooping, IGMP Authentication, Multicast Filtering |
| Advanced Features |
Automatic Device Discovery, Batch Configuration, Intelligent Network Monitoring, Unified Configuration |
| ISP Features |
L2PT, Device Link Detect Protocol (DLDP), PPPoE ID Insertion, ERPS |
| VLAN |
Max 4K VLAN Groups, 802.1q Tagged VLAN, Private VLAN, VLAN VPN (QinQ) |
| Access Control List |
Time-based ACL, MAC ACL, IP ACL, Combined ACL, IPv6 ACL |
| Security |
IP-MAC-Port Binding, DHCP Snooping, ARP Inspection, DoS Defend, 802.1X, AAA |
| IPv6 |
IPv6 Dual IPv4/IPv6, Multicast Listener Discovery Snooping, Static IPv6 Routing |
| MIBs |
MIB II, Bridge MIB, P/Q-Bridge MIB, RMON MIB, Radius Accounting Client MIB |
| MANAGEMENT |
|
| Omada App |
Yes, requires Omada Controller |
| Centralized Management |
Omada Cloud-Based Controller, Omada Hardware Controller, Omada Software Controller |
| Cloud Access |
Yes, requires Omada Controller |
| Zero-Touch Provisioning |
Yes, requires Omada Cloud-Based Controller |
| Management Features |
Web-based GUI, CLI, SNMPv1/v2c/v3, DHCP/BOOTP Client, Cable Diagnostics |
| OTHERS |
|
| Certification |
CE, FCC, RoHS |
| Package Contents |
SG3428MP Switch, Power Cord, Quick Installation Guide, Rackmount Kit, Rubber Feet |
| System Requirements |
Windows 98SE, NT, 2000, XP, Vista, 7/8/10/11, MAC OS, NetWare, UNIX, Linux |
| Environment |
Operating Temp: 0–45 ℃; Storage Temp: -40–70 ℃; Operating Humidity: 10–90% RH; Storage Humidity: 5–90% RH |
