Description
Product Description
| Category | Details |
|---|---|
| HARDWARE FEATURES | |
| Interface | • 16× 10/100/1000 Mbps RJ45 Ports • 2× Gigabit SFP Slots |
| Fan Quantity | Fanless |
| Power Supply | 100-240 V AC, 50/60 Hz |
| Dimensions | 17.3 × 7.1 × 1.7 in (440 × 180 × 44 mm) |
| Mounting | Rack Mountable |
| Max Power Consumption | 12.3 W (220 V/50 Hz) |
| Max Heat Dissipation | 41.97 BTU/hr |
| PERFORMANCE | |
| Switching Capacity | 36 Gbps |
| Packet Forwarding Rate | 26.8 Mpps |
| MAC Address Table | 8K |
| Jumbo Frame | 9 KB |
| SOFTWARE FEATURES | |
| Quality of Service | • 8 priority queues • 802.1p CoS/DSCP priority • Queue scheduling (SP, WRR, SP+WRR) |
| L3 Features | • 16 IPv4/IPv6 Interfaces • Static Routing (48 static routes) • DHCP Server |
| L2 and L2+ Features | • Link Aggregation (Static, 802.3ad LACP) • Spanning Tree Protocol (STP, RSTP, MSTP) |
| L2 Multicast | • Supports 511 IGMP groups • IGMP Snooping (v1/v2/v3) |
| Advanced Features | • Automatic Device Discovery • Batch Configuration and Firmware Upgrading |
| VLAN | • Max 4K VLAN Groups • 802.1q Tagged VLAN • Voice VLAN |
| Access Control List | • Time-based, MAC, IP, and IPv6 ACLs • Policy options for mirroring, redirect, rate limiting, QoS |
| Security | • IP-MAC-Port Binding • 802.1X Authentication • DoS Defend and Port Isolation |
| IPv6 | • IPv6 Dual IPv4/IPv6 • Static IPv6 Routing • Multicast Listener Discovery (MLD) Snooping |
| MIBs | • MIB II, Bridge MIB, and others as per RFCs |
| MANAGEMENT | |
| Omada App | Yes (requires OC300, OC200, or Omada Controller) |
| Centralized Management | • Omada Cloud-Based Controller • Omada Hardware Controller (OC300/OC200) • Omada Software Controller |
| Cloud Access | Yes (requires Omada Controller) |
| Management Features | • Web-based GUI • CLI through Telnet • SNMP v1/v2c/v3 |
| OTHERS | |
| Certification | CE, FCC, RoHS |
| Package Contents | • TL-SG2218 Switch • Power Cord • Quick Installation Guide • Rackmount Kit • Rubber Feet |
| System Requirements | Windows 98SE, NT, 2000, XP, Vista, 7/8/10/11, MAC OS, NetWare, UNIX, Linux |
| Environment | • Operating Temp: 0–40 ℃ (32–104 ℉) • Storage Temp: -40–70 ℃ (-40–158 ℉) • Humidity: 10–90% RH |
