| HARDWARE FEATURES |
|
| Processor |
Qualcomm 560MHz CPU, MIPS 74Kc |
| Memory |
64MB DDR2 RAM, 8MB Flash |
| Interface |
1 × 10/100Mbps Shielded Ethernet Port (LAN/POE) |
|
1 Reset Button |
| Power Supply |
Passive Power over Ethernet via LAN (+4,5 pins; -7,8 pins) |
|
Voltage range: 16-27V DC |
| Power Consumption |
7.41 W |
|
Note: Power drawn increases with cable length in Passive PoE |
| Dimensions (W x D x H) |
366 x 280 x 207 mm (14.4 x 11.0 x 8.1 in.) |
| Antenna Gain |
23 dBi |
| Antenna Beamwidth |
9° (Azimuth), 7° (Elevation) |
| Protection |
15KV ESD Protection, 6KV Lightning Protection |
| Enclosure |
Outdoor PC stabilized plastic, IP65 weatherproof design |
| WIRELESS FEATURES |
|
| Wireless Standards |
IEEE 802.11a/n |
| Proprietary Protocol |
TDMA Mode (with Pharos MAXtream enabled) |
| Wireless Speeds |
Up to 300Mbps (40MHz, Dynamic) |
|
Up to 144.4Mbps (20MHz, Dynamic) |
|
Up to 72.2Mbps (10MHz, Dynamic) |
|
Up to 36.1Mbps (5MHz, Dynamic) |
| Frequency |
5.15–5.85 GHz |
| Transmit Power |
Max. 25 dBm (Adjustable power by 1 dBm) |
| SOFTWARE FEATURES |
|
| Network Configuration |
WAN: Static/Dynamic/PPPoE/L2TP/PPTP |
|
LAN: Static/Dynamic/DHCP |
|
Forwarding: ALG/UPnP/Virtual Server/Port Trigger |
|
Security: SPI Firewall/Ping Forbidden/DoS Protection |
|
Access Control, Static Routing, Bandwidth Control |
|
IP & MAC Binding |
| Wireless Configurations |
Pharos MAXtream TDMA Technology |
|
Selectable Channel Width: 5/10/20/40MHz |
|
Auto Channel Selection, Transmit Power Control |
|
Dynamic Frequency Selection (DFS), WDS Enable/Disable |
|
Security: WPA/WPA2, WPA-PSK/WPA2-PSK (AES/TKIP) Encryption |
|
64/128/152-bit WEP Encryption |
|
Multi-SSID with VLAN Tagging (AP Mode only) |
| Management |
Discovery and Remote Management via Pharos Control application |
|
HTTP/HTTPS Web-based management |
|
System log, SNMP Agent (v2c), Ping Watch Dog |
|
Dynamic DDNS, SSH Server |
| System Tools |
Indicators: Signal Strength/Noise/Transmit CCQ/CPU/Memory |
|
Monitors: Throughput/Stations/Interfaces/ARP/Routes/WAN/DHCP |
|
Spectrum Analyzer, Speed Test, Ping, Traceroute, Antenna Alignment |
| System-level Optimizations |
Optimized IGMP Snooping/Proxy for multicast applications |
|
Hardware watch dog |
| POE ADAPTER FEATURES |
|
| Dimensions (W x D x H) |
85.8 × 43.9 × 29.7 mm |
| Interfaces |
1 AC Jack with Earth Ground, 1 × 10/100Mbps Shielded Ethernet Port (Power + Data), 1 × 10/100Mbps Shielded Ethernet Port (Data) |
| Button |
Remote Reset Button |
| Power Status LEDs |
Green |
| Input |
100-240VAC, 50/60Hz |
| Output |
24VDC, 0.5A Max |
|
+4,5 pins; -7,8 pins (Supports up to 60m Power over Ethernet) |
| Efficiency |
>84.29% |
| Certifications |
CE/FCC/UL/IC/GS/PSB/C-tick/SAA/S-Mark/KC-mark |
| OTHERS |
|
| Certification |
CE, FCC, IC, RoHS, IP65 |
| Package Contents |
Outdoor Wireless CPE, 24V 0.5A Passive PoE Adapter, Pole Mounting Straps, AC Power Cord, Installation Guide |
| System Requirements |
Microsoft Windows 98SE, NT, 2000, XP, Vista™, Windows 10, 8, 7, MAC OS, NetWare, UNIX, or Linux. Recommended browsers: Google Chrome, Safari, Firefox. IE not recommended. |
| Environment |
Operating Temperature: -40℃~70℃ (-40℉~158℉) |
|
Storage Temperature: -40℃~70℃ (-40℉~158℉) |
|
Operating Humidity: 10%~90% non-condensing |
|
Storage Humidity: 5%~95% non-condensing |
