Description
Product Description
Performance
- # of Cores12
- # of Threads24
- Processor Base Frequency20 GHz
- Max Turbo Frequency90 GHz
- Cache30 MB SmartCache
- Bus Speed6 GT/s QPI
- # of QPI Links2
- TDP105 W
- VID Voltage Range0
Supplemental Information
- Embedded Options AvailableYes
- Conflict FreeYes
- DatasheetView now
Learn how Intel is pursuing conflict-free technology.
Memory Specifications
- Max Memory Size (dependent on memory type)54 TB
- Memory TypesDDR4 1600/1866/2133/2400
- Max # of Memory Channels4
- Max Memory Bandwidth8 GB/s
- Physical Address Extensions46-bit
- ECC Memory Supported ‡Yes
Graphics Specifications
- Processor Graphics ‡None
Expansion Options
- Scalability2S
- PCI Express Revision0
- PCI Express Configurations ‡x4, x8, x16
- Max # of PCI Express Lanes40
Package Specifications
- Sockets SupportedFCLGA2011-3
- Max CPU Configuration2
- TCASE80°C
- Package Size45mm x 52.5mm
- Low Halogen Options AvailableSee MDDS
Advanced Technologies
- Intel® Turbo Boost Technology ‡0
- Intel® vPro™ Technology ‡Yes
- Intel® Hyper-Threading Technology ‡Yes
- Intel® Virtualization Technology (VT-x) ‡Yes
- Intel® Virtualization Technology for Directed I/O (VT-d) ‡Yes
- Intel® VT-x with Extended Page Tables (EPT) ‡Yes
- Intel® TSX-NIYes
- Intel® 64 ‡Yes
- Instruction Set64-bit
- Instruction Set ExtensionsAVX 2.0
- Idle StatesYes
- Enhanced Intel SpeedStep® TechnologyYes
- Intel® Demand Based SwitchingYes
- Thermal Monitoring TechnologiesYes
- Intel® Flex Memory AccessNo
- Intel® Identity Protection Technology ‡No
Intel® Data Protection Technology
- Intel® AES New InstructionsYes
- Secure KeyYes
Intel® Platform Protection Technology
- OS GuardYes
- Trusted Execution Technology ‡Yes
- Execute Disable Bit ‡Yes
