Description
FEATURE:
? Material: cold rolled steel 1.5mm powder coating RAL7035
? Dimension:43.4*48.9*19.3cm
? Installation method: Wall mounting and / or 19? Rack mounting
? Ingress protection: IP54
? The box has two rows of splice trays. Capacity of each row is 288F so maximum capacity is 576F
? Multiple splice tray can use for both splice and hold one splitter.
? Multiple splice trays can be used for both splicing and housing one splitter.
? Capacity of splice tray: 24F per tray + one 2:32 PLC splitter.
| Model: | FDC-2347 |
| Size( W*H*D mm) | 434*489*193 |
| NO of Cable Entry | 8 ports for cable ?18-25mm in the up 4 ports for cable ?18-25mm in the down |
| Splitter | One 2:32 bare steel tube type per tray |
| Splice Tray | 24F |
| Max Capacity | 576F |
| IP | IP54 |
| Installation Method | Indoor Wall-mounting or Rack-mounting |
